產品介紹
1. Typical capacity : 6.4 Ah
2. Nominal voltage : 3.65 V
3. Nominal energy : 23.4 Wh
4. Recommend Max. discharge current - (+60 ~ 0 oC) : 13.0 A (~2C rate)
- ( 0 ~ -40 oC) : 6.4 A (1C rate)
- (-40 ~ -50 oC) : 1.3 A (C/5 rate)
5. Typical cut-off voltage : 2.5 V
6. Charging voltage : 4.2 V
7. Max. continuous charge current - (+60 ~ 0 oC) : 6.4 A (1C rate)
- ( 0 ~ -30 oC) : 1.3 A (C/5 rate)
8. Operating temperatures - Charge : -30 ~ +60 oC
- Discharge : -50 ~ +60 oC
9. Storage & transportation temperatures - Recommend : +15 ~ +30 oC
- Allowable : -50 ~ +85 oC
10. Thickness : 18.65 mm
11. Width : 60.5 mm
12. Height (including terminals) : 68.7 mm
13. Typical weight : 134 g
