產品介紹
1. Typical capacity : 6.8 Ah
2. Nominal voltage : 3.65 V
3. Nominal energy : 24.8 Wh
4. Recommend Max. discharge current - Continuous : 14.0 A (~2C rate)
- Pulse : 27.0 A (~4C rate)
5. Typical cut-off voltage : 2.5 V
6. Charging voltage : 4.2 V
7. Max. continuous charge current : 6.8 A (~1C rate)
8. Operating temperatures - Charge : -30 ~ +60 oC
- Discharge : -35 ~ +60 oC
9. Storage & transportation temperatures - Recommend : +10 ~ +30 oC
- Allowable : -40 ~ +60 oC
10. Thickness : 19.6 mm
11. Width : 60.1 mm
12. Height (including terminals) : 65.2 mm
13. Typical weight : 150 g
